DG-430系列 Series |
馬達 |
型號 |
曲線編號 |
頻率 |
功率 |
電壓 |
滿載額定電流 |
靜壓 |
最大風量 |
噪音 |
重量 |
|
Motor |
Model |
Curve No. |
Frequency |
Output |
Voltage |
Current |
Static pressure |
Max |
Noise |
Weight |
|
|
|
|
|
|
|
|
Vacuum / Compressor |
Airflow |
|
|
|
|
|
|
(Hz) |
(kw) |
(V) |
(A) |
(mbar) |
(m3/min) |
(dB)A |
(Kg) |
|
三相 Three Phase |
DG-430-16 |
50 |
3.4 |
200-240Δ/345-415Y |
12.5Δ/7.20Y |
345/410 |
3.7 |
74 |
40 |
|
|
60 |
3.7 |
220-275Δ/380-480Y |
13.5Δ/7.80Y |
370/350 |
4.4 |
77 |
|
||||
DG-430-26 |
50 |
4 |
200-240Δ/345-415Y |
14.3Δ/8.20Y |
355/460 |
3.7 |
74 |
43 |
|
||
60 |
4.6 |
220-275Δ/380-480Y |
16.2Δ/9.30Y |
410/475 |
4.4 |
77 |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
附註/Remark: |
|||||||||||
1. 上述資料供參考,如有不同以實品為主。 Information above is for reference, product only when different. |
|||||||||||
2. 本公司保有設計變更之權利,恕不另行通知。We reserve the right to change the design without notice. |
|||||||||||
3. 如有任何疑問請洽經銷商或本公司。 Should you require any further information or assistance, please do not hesitate to contact us or distributors. |
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
