DG-640系列 Series |
|
馬達 |
型號 |
曲線編號 |
頻率 |
功率 |
電壓 |
滿載額定電流 |
靜壓 |
最大風量 |
噪音 |
重量 |
|
|
Motor |
Model |
Curve No. |
Frequency |
Output |
Voltage |
Current |
Static pressure |
Max |
Noise |
Weight |
|
|
|
|
|
|
|
|
|
Vacuum / Compressor |
Airflow |
|
|
|
|
|
|
|
(Hz) |
(kw) |
(V) |
(A) |
(mbar) |
(m3/min) |
(dB)A |
(Kg) |
|
|
三相 Three Phase |
DG-640-36 |
50 |
5.5 |
200-240Δ/345-415Y |
21.6Δ/12.5Y |
200/220 |
7.9 |
75 |
78 |
|
|
|
60 |
6.3 |
220-275Δ/380-480Y |
26.5Δ/15.3Y |
180/170 |
9.5 |
79 |
|
||||
|
DG-640-46 |
50 |
7.5 |
200-240Δ/345-415Y |
31.5Δ/18.2Y |
240/275 |
7.9 |
75 |
82 |
|
||
|
60 |
8.6 |
220-275Δ/380-480Y |
37.0Δ/21.3Y |
260/260 |
9.5 |
79 |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
附註／Remark： |
|||||||||||
|
1. 上述資料供參考，如有不同以實品為主。 Information above is for reference, product only when different. |
|||||||||||
|
2. 本公司保有設計變更之權利，恕不另行通知。We reserve the right to change the design without notice. |
|||||||||||
|
3. 如有任何疑問請洽經銷商或本公司。 Should you require any further information or assistance, please do not hesitate to contact us or distributors. |
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
